Hinge drill

This machine is mainly suitable for processing both ends of aluminum alloy casement window series. The idea of the machine combines the requirements of the use of customers, specially designed a kind of aluminum alloy flat open window sash, both ends of the perforated drilling machinery processing; Unique high precision guide rail and special guide rail base multi-point support, good rigidity, to ensure the accuracy of the machine and the stable performance of the operation; Suitable for most manufacturers of accessories, hole distance adjustment for manual adjustment, easy and simple adjustment, drilling seat feed driven by the cylinder, feed smooth, stepless speed regulation, a clamping, a molding, simple operation, high processing accuracy, fast speed, greatly improve the work efficiency, is now one of the aluminum doors and Windows industry must be selected.

Main Technical Parameters:

Weight of machine：600kg
Overall Dimension：3400mm×600mm×1200mm
Processing range length：310mm～1850mm
Hole distance：24～300mm
Motor speed：2800r/min
The hole diameter：0.6～6mm
Motor power：1.5kw×2
Machining accuracy：±0.2mm
Working voltage：380V 50Hz
Working pressure：0.6～0.8Mpa
